High-performance hinged window and balcony systems.

With 74 mm deep frames, a hidden drainage system and a thermal transmittance from 1.1 W/m2K, it is a high-quality system, suitable for any climate zone. Its insulation is also reinforced by tubular polyamide sheets.

Its minimalist aesthetic with an exposed blade of only 23 mm and its reduced central knot provide great visual elegance to the system, with straight lines and coplanar to the exterior.

Available in a version with exposed leaves and hidden leaves.

Performance characteristics
Air permeability
CLASS 4
Watertightness
E1200
Wind resistance
C5
Soundproofing
Rw ≤ 46 dB
Thermal transmittance
Uw ≥ 1,1 W/m2K
Dimensions
Glazing

Viewed sash: 32/42 mm
Hidden sash: 32 mm

Maximum dimensions

Sash width (L) = 1200 mm
Sash height (H) = 2600 mm

Maximum weight per sash

100/130 kg

Sections
Frame: 74 mm
Sash: 82,5 mm
