The ideal solution for high traffic access doors.
System for access doors with coplanar frames and leaves to the interior and exterior with straight line design.
Frames and leaves 72.5 mm.
System of coplanar pedestrian doors with straight lines of European channel.
Compatible with accessories and elements of the Strugal S64RP series.
System with central joint and possibility of reduced frame.
This system can be used for emergency exits that incorporate panic exit devices in accordance with EN 179 and EN 1125.
Sill profile with thermal bridge break and triple frame sealing gasket.
Possibility of 2 levels of thermal insulation using polyolefins: Basic and Efficiency [E].
System of coplanar pedestrian doors with straight lines of European channel.
Compatible with accessories and elements of the Strugal S64RP series.
System with central joint and possibility of reduced frame.
This system can be used for emergency exits that incorporate panic exit devices in accordance with EN 179 and EN 1125.
Sill profile with thermal bridge break and triple frame sealing gasket.
Possibility of 2 levels of thermal insulation using polyolefins: Basic and Efficiency [E].
Dimensions
Glazing
Maximum thickness 51 mm
Maximum dimensionsSash width (L) = 1400 mm
Sash height (H) = 2700 mm
Channel hinges: 80-100-120 kg
Coplanar hinges: 160 kg
