Minimalist aesthetics for large architectural spaces.
Belonging to the minimalist range, it allows to obtain great luminosity and total visibility by opening spaces up to 4 m high. Its high thermal and acoustic performance provides very high comfort values.
157 mm frames with the possibility of miter cut or straight cut.
The frame can be completely hidden in a masonry wall.
Just 10 mm of sash exposed face.
Fittings designed for heavy sashes up to 500 kgs with 42 mm thick glass.
Easy and flexible movement thanks to its rolling system equipped with stainless steel hidden wheels which also enables the adjustment of the sashes.
Optional single-rail.
It allows to open up spaces up to 4 m height.
Maximum thermal and sound performance.
Minimalist aesthetics with only 27 mm central node and possibility of meeting leaves in a corner at 90º without vertical mullions.
The frame can be completely hidden in a masonry wall.
Just 10 mm of sash exposed face.
Fittings designed for heavy sashes up to 500 kgs with 42 mm thick glass.
Easy and flexible movement thanks to its rolling system equipped with stainless steel hidden wheels which also enables the adjustment of the sashes.
Optional single-rail.
It allows to open up spaces up to 4 m height.
Maximum thermal and sound performance.
Minimalist aesthetics with only 27 mm central node and possibility of meeting leaves in a corner at 90º without vertical mullions.
Dimensions
Glazing
42 mm thickness
Maximum weight per sash250 kg and 500 kg
Notional average thickness2,0 mm
